1. Rope Colors:
Our outdoor playground obstacle course are available in a wide selection of colors, offering excellent flexibility for customization. Different color combinations can be tailored to suit various playground styles, and project requirements. The bright and attractive colors enhance the overall visual impact of the playground, making climbing activities more appealing to children, while also helping create a fun, energetic, and well-designed outdoor play environment.
2. Rope Material:
Our outdoor playground obstacle course are made of six-strand steel wire core, offering exceptional strength, stability, and durability. Compared with ordinary ropes, the six-strand steel wire structure provides higher tensile strength and excellent load-bearing capacity, ensuring long-term safety even under frequent use. The steel core effectively prevents excessive stretching and deformation, while the outer rope layer delivers a comfortable grip and enhanced wear resistance. This makes the rope ideal for outdoor playground equipment, maintaining reliable performance in various weather conditions and significantly extending its service life.
3. Connectors:
The connectors are made of high-quality aluminum alloy with anodized surface treatment. The anodizing process creates a dense protective layer on the aluminum surface, significantly improving corrosion resistance and wear resistance. This makes the connectors highly suitable for long-term outdoor use, even in humid or harsh environments. In addition, anodized aluminum offers higher surface hardness, stable performance, and a smooth finish, enhancing both safety and durability while maintaining a clean and attractive appearance over time.
4.Metal Parts:
Post: ￠114*2.0 galvanized steel pipe (diameter 114mm, thickness 2.5mm)
Color coating: The main purpose is to prevent rust, UV, improve aesthetics and corrosion resistance，The paint temperature and thickness of outdoor slide steel parts (such as columns, connectors, brackets, and guardrails) are very critical.
Temperature: 220℃, 30 minutes, so that the iron parts will not turn yellow after long-term exposure, and have anti-UV and anti-aging properties,The rust resistance of galvanized steel pipes can withstand harsh climates;
Paint thickness: 70–100 µm is the optimal range, and our paint thickness exceeds 100 µm, which is not easy to rust and peel, and has a longer service life,powder coating pigment, make the color long-lasting bright, strong adhesion, environmental protection, non-toxic, safe
5.Metal Parts Production Processes:
5.1.Cutting, the automatic cutting machines can cut pipes to length accurately and efficiently
5.2.Curving,use special semi-automatic pipe bending machine,it can precisely set the bending angle
5.3.Welding,Use carbon dioxide shielded welding, high efficiency and stable weld quality
5.4.Polishing,Eliminate burrs, and welding slag on the surface of steel parts to make it smoother and facilitate subsequent painting or surface treatment
5.5.Sand Blasting,it is not only improves the adhesion of the coating, but also retains a certain degree of roughness to facilitate the leveling of the coating
5.6.Color coating: It not only makes the appearance more beautiful, but more importantly, it is anti-corrosion,anti-rust and prolongs the service life
The metal parts are made from high-strength, corrosion-resistant steel and processed according to stringent manufacturing standards to ensure superior structural strength, stability, and safety.
This combination of premium materials makes our outdoor playground obstacle course safer, stronger, and more durable than similar products commonly found on the market.
Safety & Certifications
GS Certificate Issued by TUV SUD
WeYou outdoor playground obstacle course are designed and manufactured in compliance with European Norm (EN1176-1:2008) so as to minimize the injury hazards during play, as we understand how critical it would be to the business of our customers.
Our outdoor playground obstacle course are fully certified to meet international safety standards, including EN 1176 and related national requirements. Each product has passed rigorous testing for structural stability, anti-entrapment, and material safety, ensuring every play experience is both fun and secure.
Stand Mesh Size: ≤ 80 mm or ≥ 230 mm
Our obstacle course is designed and manufactured in compliance with international playground safety standards. The mesh size is precisely controlled, with all openings either smaller than 89 mm or larger than 230 mm, effectively avoiding the hazardous range between 89 mm and 230 mm. This ensures that there is no risk of head or neck entrapment, providing a safe, secure, and reliable climbing experience for children.
Head and Neck Entrapment Standard
The obstacle course must not contain structures or openings that could cause a child’s head or neck to become entrapped. Pay particular attention to slide entrances, climbing platform railings, and the area where the chute edge connects to the handrail. All openings accessible to, climbable by, or probing by children must be tested for entrapment.
If a small probe can fit through the opening, but a large probe cannot, with an aperture range of 45 mm–230 mm, the equipment is considered to have a entrapment or neck entrapment hazard.
If both probes can fit through, or neither can fit through, with a safety aperture size of less than 45 mm or greater than 230 mm, the equipment is considered safe
Our outdoor playground obstacle course are designed and manufactured in strict accordance with international safety standards. Every component—from plastic parts to metal structures—undergoes thorough testing to ensure durability, stability, and child safety. You can trust that our products are built to provide a safe, reliable, and worry-free play experience.
Installation & Maintenance
We provide detailed assembly instructions to make sure that our customers could install the outdoor playground obstacle course on their own.
We provide comprehensive instruction manuals for all our outdoor playground obstacle course to ensure a safe, smooth, and enjoyable installation process.
Each manual includes:
Step-by-step assembly guidance, clearly illustrated to make installation straightforward for installers or end users.
Safety instructions, highlighting areas prone to entrapment, pinch points, or other potential hazards, to ensure childre’s play is always secure.
Maintenance tips and care recommendations, including how to inspect rope net, clean surfaces, and prolong the life of the rope net.
Our goal is to provide not just a high-quality outdoor playground obstacle course, but also all the support needed so that every setup is safe, durable, and worry-free for children and parents alike.
Detailed Manuals-Assembly Instructions （sample）
Our outdoor playground obstacle course can be installed with either in-ground anchoring or expansion bolts on concrete. We provide detailed installation instructions, and our team can also offer on-site or remote installation support if needed.
If your grouond is concrete, we recommend choosing surface mount type, please ensure the concrete is 15cm thick. If the concrete is too thin, the expansion screws can crack or crumble under stress (especially upward pull and lateral rocking forces), rendering the anchor ineffective and potentially causing the slide to tip over.
If your ground is grass or sand, we recommend choosing inground type. This requires digging some 30-60cm deep pits and then pouring concrete to fix it when installing
both are very secure; it all depends on the type of floor you have.
1.Inground type: lengthen the posts,for soft ground, like grass ground, choose inderground type
2. Surface mount type: for hard ground, like concrete, choose surface mount type
How to maintain outdoor playground obstacle course
Installation & Maintenance Manual
1. Installation Requirements
1.1 Installation must be carried out by trained and qualified personnel in accordance with the approved installation drawings and local safety regulations.
1.2 All foundations, anchor points, and fixing methods must meet the design specifications to ensure structural stability.
1.3 Ensure that all bolts, flanges, connectors, and fasteners are correctly installed and securely tightened before use.
1.4 After installation, a full safety inspection must be completed prior to opening the equipment to users.
2. Daily Inspection
A daily visual inspection should be conducted to identify any obvious safety hazards, including but not limited to:
2.1 Damaged or worn ropes
2.2 Loose connectors, bolts, or fasteners
2.3 Exposed steel cores or sharp edges
2.4 Missing components or abnormal deformation
Any identified issues must be addressed immediately before the equipment is used.
3. Periodic Inspection
Periodic inspections should be carried out at regular intervals depending on usage intensity and environmental conditions. These inspections should include:
3.1 Rope tension and surface wear
3.2 Structural integrity of posts and frames
3.3 Condition of connectors, flanges, and fasteners
3.4 Signs of corrosion, fatigue, or material aging
Adjustments, repairs, or replacements should be performed as necessary.
Packaging & Shipping
Professional loaders are responsible for loading the containers, ensuring that each piece of cargo is loaded into the container in the safest and most efficient way.
Our experienced team carefully plans the layout, stacking, and protection of each part before sealing the containe。they also could part the irregular shaped parts in a compact way to save your shipping cost.
We also provide free installation tools. All accessories such as screws, nuts, and fasteners are well categorized and packed separately in bags, making it easy for you to find and install them efficiently.
Strong Protection for Long-Distance Transport
Our protective film is made of woven fabric and EVA foam, which is tough, wear-resistant, and waterproof. The bottom is thickened with EVA to prevent scratches and wear during transportation.
It is environmentally friendly and can be laid on the ground to protect the floor when the house is renovated. It can be reused.
All components are carefully wrapped with multiple protective layers — including EVA foam, PE plastic wrapping and pp film
This ensures every metal post and plastic part stays intact during long-distance sea and land transportation.
This advanced packaging method provides superior cushioning, scratch resistance, and moisture protection during long-distance transportation
Scratch Protection
Each plastic part is first wrapped with bubble film and then covered with a PP film layer.
This double-layer protection prevents scratches, moisture, and dust, while keeping the parts clean and safe during transport and storage
The double-layer packaging method of “bubble film + PP film” ensures that plastic parts maintain a smooth surface, no scratches, deformation, and moisture during long-distance sea transportation or storage, and the overall protection performance is improved by about 30%-40%.
Our product packaging is good quality, ensuring that each product is securely protected during transit. We use durable materials and carefully designed packaging to prevent any damage, ensuring that the products arrive in perfect condition for our customers.
FAQ
1.What is the production lead time?
The production usually takes 7-15 days, depending on the product type and order quantity
2.How long does shipping take?
Shipping usually takes about 7–15 days to Asia and Oceania, and around 30 days to Africa, Europe, and the Americas, depends on the specific port
3. What are the payment terms?
We accept T/T, with payment terms of 30% deposit and 70% before shipment.
4.Do you also provide transportation and delivery services?
Yes, we provide one-stop solutions, including everything from design and manufacturing to shipping and installation
5.What is the warranty period for your products?
Our products typically come with a 1-year warranty
